ID: 100128447
4220 12-P CM STACKABLE SWITCH
Этот продукт снят с производства
К сожалению, товара нет в наличии.
Enterprise 12 port Gigabit stackable PoE switch with 4 SFP plus uplinks.
General
-
Best forEnterprise access, Branch offices, Aggregation
-
Тип шассиFixed-configuration stackable switch
-
ColorPurple
-
Fan ConfigurationFixed internal fans, supports silent mode operation
-
Скорость пересылки95 Mpps forwarding rate
-
Front Panel IndicatorsPer-port status LEDs and system LEDs for power, status, and activity
-
ЗадержкаApproximately 3.5 microseconds (10G ports)
-
MAC Address Table Size16K MAC addresses
-
Mode ButtonFront-panel mode button for control and reset functions
-
Model4220-12P-4X
-
Варианты монтажаRack-mountable with included rack-mount kit
-
MTBFMore than 200,000 hours
-
PoE Budget240 W total PoE power budget
-
PoE Standard802.3at
-
Product Line4220 Series
-
Тип продуктаNetwork switch, stackable PoE switch
-
Rack Units1U
-
SeriesExtremeSwitching 4220 Series
-
Silent Mode Temperature RangeSilent mode operation supported up to 35°C (95°F)
-
Stacking Speed40Gb
-
Stacking TopologySupports stacking of up to 8 systems using SFP+ ports
-
System LEDsFront-panel system LEDs for status indication
Сеть
-
Ethernet Ports12 x 10/100/1000Base-T
-
Management Port1 x 10/100/1000BASE-T out-of-band management port
-
Multi-Gigabit PoE Port Details4 x 1G/2.5G/5GBase-T 802.3bt PoE ports (90W)
-
Non-Multigigabit PoE Port Details8 x 10/100/1000Base-T 802.3at PoE ports (30W)
-
Out-of-Band Management Port Type1 x 10/100/1000BASE-T RJ-45 management port
-
PoE Ports12
-
PoE Power per Port30 W
-
Port Count12
-
RJ-45 PoE Port Configuration12 x 10/100/1000Base-T 802.3at PoE ports
-
SFP+ Uplink Port Details4 x 1/10Gb SFP+ uplink or stacking ports (unpopulated by default)
-
Supported Stacking Speed OptionsSupports 10Gb and 40Gb logical stacking configurations
-
Uplink/Stacking Ports4 x 1/10Gb SFP+
-
Uplink / Stacking Port StatusUnpopulated
Physical
-
Форм-факторRack-mountable
-
Power Supply Form Factor1 fixed internal AC power supply
Власть
-
Idle Power ConsumptionApproximately 40 W without PoE load
-
Maximum Input Current2.5 A at 100 VAC
-
Maximum System Power ConsumptionApproximately 300 W with full PoE load
-
Number of Power Supplies Installed1
-
Тип источника питанияInternal fixed AC power supply
Память
-
Input Voltage Range100 - 240 VAC, 50/60 Hz
-
Буферная память пакетов4 MB packet buffer
Хранилище
-
Management Interface OptionsSupports out-of-band Ethernet management and USB-based management
-
Switching Fabric Capacity128 Gbps switching capacity
-
USB Interface1 x USB Type-A port
Информация о поставщике
-
Гарантия1
