PMP 450 SUBSCRIBER MODULE

Cambium Networks PMP 450 Subscriber Module C054045C004B is a 5 GHz point-to-multipoint unit for the subscriber side of fixed outdoor wireless broadband networks. This exact model is the uncapped-throughput version, with an integrated patch antenna; connectorized models have different part numbers.

It provides a 10/100Base-T Ethernet interface and uses 2×2 MIMO-OFDM. Selectable channel widths from 5 to 40 MHz allow the network to be configured for its radio environment. The platform also supports GPS synchronization through compatible Cambium synchronization equipment.

The unit is specified with an IP55 environmental rating and measures 30 × 9 × 9 cm, with a weight of 0.45 kg. Its listed input voltage is 20–32 V, and typical power consumption for the 5 GHz model is 9 W. Cambium describes the platform for fixed outdoor broadband deployments serving wireless providers, enterprises and public-safety networks.
