EAN
190017355498
In stock: 10-19
Delivery: 2–4 weeks
The Aruba Instant On 1930 switch series is designed for small and growing businesses that require enhanced performance to support bandwidth-demanding applications. The Aruba Instant On 1930 switch series seamlessly integrates with existing Instant On indoor/outdoor access points and can be centrally managed with the Instant On mobile app onsite or remotely. These cloud-managed layer 2+ Ethernet switches consist of 8-, 24-, and 48-port Class 4 PoE (i.e. PoE+) and non-PoE Gigabit Ethernet models, with 1G SFP slots on 8-port model and 1G/10G SFP+ slots on 24-/48G models for fiber connectivity.
Features
Simplify Network Deployment and Management for Small Organizations
- The Aruba Instant On 1930 switch series features easy-to-use, out-of-the-box, plug-and-play deployment.
- The series offers a complete portfolio of choices for increased small business flexibility. It consists of seven models including 8G-, 24G-, and 48G-ports with and without class 4 PoE (i.e. PoE+).
- The 24- and 48- port models include four SFP/SFP+ transceiver slots that support Gigabit or 10-Gigabit speeds for fiber connectivity.
- The Aruba Instant On 1930 switch series can be deployed using two management modes – Instant On cloud-management (access via mobile app and/or web portal) and the local web GUI.
Keep Your Business Protected with Integrated Security Features
- The Aruba Instant On 1930 switch series supports energy efficient Ethernet for lower power consumption and an enhanced feature set for more robust operation.
- Enhanced security features such as IEEE 802.1x, and VLANs guard your network from unwanted or unauthorized access.
- Automatic denial-of-service (DOS) monitors and protects the network against malicious attacks.
- Management security restricts access to critical configuration commands, offers multiple privilege levels with password protection.
Deliver High Perfomance
- The Aruba Instant On 1930 switch series delivers advanced functionalities including customizable like VLANs, link aggregation, Spanning Tree Protocols, and IEEE 802.1X access control.
- 8-, 24-, and 48-port configurations with a choice of non-PoE and Class 4 PoE models provides deployment flexibility that fits all small business environment. Class4 PoE options allow to power devices like IP phones, surveillance cameras and access points, without the cost of additional cabling.
- The 24- and 48-port models include 1G/10G SFP+ ports for reliable fiber connectivity and other connections across longer distances.
- The switch series is covered by the Limited Lifetime Warranty with 24x7 phone support for 90 days and chat support for the entire warranty duration.
Features
Simplify Network Deployment and Management for Small Organizations
- The Aruba Instant On 1930 switch series features easy-to-use, out-of-the-box, plug-and-play deployment.
- The series offers a complete portfolio of choices for increased small business flexibility. It consists of seven models including 8G-, 24G-, and 48G-ports with and without class 4 PoE (i.e. PoE+).
- The 24- and 48- port models include four SFP/SFP+ transceiver slots that support Gigabit or 10-Gigabit speeds for fiber connectivity.
- The Aruba Instant On 1930 switch series can be deployed using two management modes – Instant On cloud-management (access via mobile app and/or web portal) and the local web GUI.
Keep Your Business Protected with Integrated Security Features
- The Aruba Instant On 1930 switch series supports energy efficient Ethernet for lower power consumption and an enhanced feature set for more robust operation.
- Enhanced security features such as IEEE 802.1x, and VLANs guard your network from unwanted or unauthorized access.
- Automatic denial-of-service (DOS) monitors and protects the network against malicious attacks.
- Management security restricts access to critical configuration commands, offers multiple privilege levels with password protection.
Deliver High Perfomance
- The Aruba Instant On 1930 switch series delivers advanced functionalities including customizable like VLANs, link aggregation, Spanning Tree Protocols, and IEEE 802.1X access control.
- 8-, 24-, and 48-port configurations with a choice of non-PoE and Class 4 PoE models provides deployment flexibility that fits all small business environment. Class4 PoE options allow to power devices like IP phones, surveillance cameras and access points, without the cost of additional cabling.
- The 24- and 48-port models include 1G/10G SFP+ ports for reliable fiber connectivity and other connections across longer distances.
- The switch series is covered by the Limited Lifetime Warranty with 24x7 phone support for 90 days and chat support for the entire warranty duration.
Network
-
10G supportNo
-
Active link detectionYes
-
Auto MDI/MDI-XYes
-
Auto-sensingYes
-
Auto-Sensing PortsAll 24 RJ-45 ports auto-sense speed (10/100/1000 Mbps)
-
Copper ethernet cabling technology1000BASE-T
-
Direct Attach SupportSFP+ Direct Attach cables supported on all 4 SFP+ ports
-
Ethernet LAN data rates10/100/1000
-
Flow control supportYes
-
Full duplexYes
-
IP routingYes
-
Layer SupportLayer 2+ (Data Link + Network Layer features)
-
Link aggregationYes
-
Networking standardsIEEE 802.1p/IEEE 802.1Q/IEEE 802.1x/IEEE 802.3/IEEE 802.3ab/IEEE 802.3u/IEEE 802.3x
-
Number of VLANs4093
-
PoE SupportNot supported (non-PoE model)
-
Port Configuration24x 10/100/1000 Mbps RJ-45 + 4x SFP+ 1/10 Gigabit Ethernet
-
Port mirroringYes
-
Rate limitingYes
-
Routing entries32
-
SFP Port Support4x SFP+ ports supporting 1 Gigabit and 10 Gigabit Ethernet
-
Spanning tree protocolYes
-
Supported protocolsIEEE 802.3 (10BASE-T), IEEE 802.3u (100BASE-TX), IEEE 802.3ab (1000BASE-T), IEEE 802.3z (1000BASE-X), IEEE 802.3ae (10GBASE-SR/LR)
-
Total Ports28 ports (24 Gigabit + 4 SFP+)
-
VLAN supportIEEE 802.1Q VLAN tagging, Yes
Security
-
Access Control List (ACL)Yes
-
BPDU filtering/protectionYes
-
DHCP featuresDHCP client/DHCP snooping
-
IGMP snoopingYes
-
Loop protectionYes
-
SSH/SSL supportYes
Power
-
AC input frequency50 - 60, 50-60 Hz
-
AC input voltage200 - 240
-
Idle Power Consumption9.3 W
-
Input current0.2, 0.5 A / 0.3 A
-
Maximum Power Consumption22.6 W
-
Power consumption (max)22.6
-
Power sourceAC
-
Power supply includedYes
-
Power supply typeInternal power supply
Memory
-
AC input voltage100-240V AC
-
Memory (SDRAM)512 MB
Management features
-
ARP inspectionYes
-
Cloud-managedYes
-
Quality of Service (QoS) supportYes
-
Switch layerL2/L3/L4
-
Switch typeManaged
-
System event logYes
-
Web-based managementYes
Ports & interfaces
-
Basic switching RJ-45 Ethernet ports quantity24
-
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
-
SFP+ module slots quantity4
General
-
Best forSMB Branch Networks, Retail Deployments, Office.
-
Duplex Mode10BASE-T/100BASE-TX: half or full duplex; 1000BASE-T: full duplex only
-
Latency at 10000 Mbps<1.3 microseconds
-
Latency at 1000 Mbps<2.4 microseconds
-
Latency at 100 Mbps<4.7 microseconds
-
LED indicatorsLink/Status LED per port, Cloud Status LED, Global Status LED, UID LED, Speed Mode LED, PoE Mode LED
-
LED Mode ButtonLED Mode pushbutton for LED display control
-
MAC Address Table Size16,000 entries
-
Model NameHPE Networking Instant On 1930 24G 4SFP/SFP+ Switch
-
Mounting optionsRack-mount (standard 19-inch equipment rack); can be mounted top surface up or upside down
-
MTBF (Mean Time Between Failures)158 years
-
Noise levelNot specified in available documentation
-
Operating HumidityNot specified in available documentation
-
Operating Temperature0°C to 40°C (32°F to 104°F)
-
Packet Buffer1.5 MB
-
Product LineInstant On 1930 Series
-
Product typeManaged Layer 2+ Ethernet Switch
-
Reset buttonRecessed reset pushbutton
-
Routing Table Size32 static entries
-
Throughput95.23 Mpps (Million Packets Per Second)
-
Transceiver CompatibilityHPE-approved SFP+ transceivers only
Vendor information
-
Brand NameHewlett Packard Enterprise
-
Warranty1
Performance
-
Built-in processorYes
-
FanlessYes
-
Flash memory256
-
Internal memory512
-
Memory typeSDRAM / Flash
-
Processor frequency800
-
Processor modelARM Cortex-A9
Storage
-
Flash memory256 MB
-
Management InterfaceInstant On Portal (cloud-based), Web browser, SNMP v1/v2c/v3
-
Storage TemperatureNot specified in available documentation
-
Switching capacity128 Gbps non-blocking
Design
-
Form factor1U
-
Product colourWhite
-
Rack mountingYes
-
StackableYes
Physical
-
Form factorRack-mountable 1U
-
Physical DimensionsNot specified in available documentation
-
WeightNot specified in available documentation
Data transmission
-
Jumbo frames9216
-
Jumbo frames supportYes
-
Latency (10-100 Mbps)4.7
-
Latency (10 Gbps)1.3
-
Latency (1 Gbps)2.4
-
MAC address table16000
-
Packet buffer memory1.5
-
Switching capacity128
-
Throughput95.23
Multicast features
-
Multicast supportYes
Operational conditions
-
Operating altitude0 - 3000
-
Operating relative humidity (H-H)15 - 95
-
Operating temperature (T-T)0 - 40
-
Storage relative humidity (H-H)15 - 95
-
Storage temperature (T-T)-40 - 70
Power over Ethernet (PoE)
-
Power over Ethernet (PoE)No
Processor
-
ProcessorARM Cortex-A9 @ 800 MHz
