ID: 100014156
1000T 8P GS108PP
OEM Number
EAN
606449130034
This product is discontinued
Unfortunately, the product is out of stock.
1000T 8P GS108PP GS108PP, Unmanaged, Gigabit Ethernet (10/100/1000), Full duplex, Power over Ethernet (PoE), Rack mounting,
Network
-
10G supportNo
-
Ethernet Ports8 x Gigabit Ethernet (10/100/1000) RJ-45 ports; Full duplex
-
Full duplexYes
-
Networking standardsIEEE 802.1p/IEEE 802.3af/IEEE 802.3at/IEEE 802.3az/IEEE 802.3x
-
Network StandardsIEEE 802.1p, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3x
-
PoE Ports8 x PoE+ (802.3af/at); 30 W per port max
Ports & interfaces
-
Basic switching RJ-45 Ethernet ports quantity8
-
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
General
-
Best forIP Surveillance, VoIP Telephony, Wireless Networks
-
Buffer size192 KB
-
Compliance CertificationsCE, FCC, ICES-003, VCCI, RCM, BSMI, KC, CB, CE LVD, BSMI, EAC, RCM, KC, EN 60950-1
-
Fanless DesignFanless operation
-
MAC address table4000 entries
-
ModelGS108PP
-
MTBF2,752,476 hours
-
Operating altitude0 - 3000 m
-
Operating Humidity0 - 90 % non-condensing
-
Operating Temperature0 - 40 °C
-
Product LineGigabit Unmanaged Switch series
-
Product typeUnmanaged Gigabit Ethernet Switch
-
Status LEDsPower, per-port Link/Speed/Activity
-
Total PoE Budget123 W
Vendor information
-
Brand NameNetgear
-
Warranty1
Performance
-
Buffer size192
-
Mean time between failures (MTBF)2752476
-
Plug and PlayYes
Design
-
CertificationCE, FCC, ICES-003, VCCI, RCM, BSMI, KC, CB, CE LVD, BSMI, EAC, RCM, KC, EN 60950-1
-
LED indicatorsYes
-
Product colourBlack
-
Rack mountingYes
-
Wall mountableYes
Power
-
DC input voltage54
-
Max Wattage123 W typical consumption; DC input 54 V
-
Output voltage2.4
-
Power consumption (typical)123
-
Power sourceDC
-
Power SuppliesExternal DC; 130W adapter included (EPS130W); Supports 67.5W/90W/130W for PoE budget adjustment
Physical
-
Dimensions236 mm Width x 102 mm Depth x 27 mm Height
-
Form factorDesktop; Wall mountable; Rack mountable
-
Weight600 g
Data transmission
-
Jumbo frames9000
-
Jumbo frames supportYes
-
MAC address table4000
-
Switching capacity16
Memory
-
Jumbo frames9000 bytes
Operational conditions
-
Operating altitude0 - 3000
-
Operating relative humidity (H-H)0 - 90
-
Operating temperature (T-T)0 - 40
-
Storage relative humidity (H-H)0 - 95
-
Storage temperature (T-T)-20 - 70
Power over Ethernet (PoE)
-
Power over Ethernet plus (PoE+) ports quantity8
-
Power over Ethernet (PoE)Yes
-
Power over Ethernet (PoE) power per port30
-
Total Power over Ethernet (PoE) budget123
Management features
-
Quality of Service (QoS) supportYes
-
Switch typeUnmanaged
Storage
-
Storage Humidity0 - 95 % non-condensing
-
Storage Temperature-20 - 70 °C
-
Switching capacity16 Gbit/s
