ID: 101515748
28-PORT 10GB SMART SWITCH
OEM číslo
Tento produkt byl ukončen
Bohužel produkt není skladem.
Smart managed switch with 24 10GBASE-T ports and 4 SFP+ ports.
Síť
-
10GBase-T RJ-45 Ports24 x 100/1000/10GBase-T RJ-45 copper ports
-
Konzolový port1 x RS-232 serial console port
-
IPv6 SupportIPv6 for management, QoS and ACL
-
Layer SupportLayer 2+
-
Queue Per Port8 hardware queues per port
-
SFP+ Ports4 x 1000/10GBase-X SFP+ fibre ports (dedicated)
-
SNMP SupportSNMP v1, v2c, v3
-
Supported Ethernet StandardsIEEE 802.3an 10GBase-T; IEEE 802.3ab 1000Base-T; IEEE 802.3u 100Base-TX
-
Total Ports28 ports
-
USB Ports1 x USB port
-
podpora VLANPort-based; IEEE 802.1Q tag-based; Voice VLAN; Guest VLAN; MAC-based VLAN
General
-
Auto-MDI/MDI-XYes, on all copper ports
-
Best forServer access, Fiber uplinks, SMB networks
-
Flow ControlIEEE 802.3x full-duplex flow control
-
sazba za přeposílání416.7 Mpps
-
LatenceLow latency store-and-forward
-
Agregace odkazůIEEE 802.3ad LACP; static LAGs
-
Loop DetectionCable diagnostics and loop detection
-
MAC Address Table Size16K
-
Management TypeSmart Managed
-
ModelXS728T
-
Typ montážeRack-mountable; Desktop
-
Number of LAGs8 LAGs with up to 8 members each
-
Počet statických tras32 static routes
-
Počet VLAN256 VLANs
-
Part ClassSwitch
-
Private VLANPrivate VLAN (Protected Ports)
-
Product CategoryNetwork Switches
-
Product LevelSMB switching
-
Product LineProSAFE
-
Typ produktu10-Gigabit Ethernet Smart Managed Switch
-
QoS FeaturesIEEE 802.1p; DSCP-based QoS; port-based QoS; WRR and strict priority
-
Rack Units1U
-
Routing CapabilitiesStatic routing for IPv4 and IPv6
-
Bezpečnostní prvkyACLs; 802.1X port-based authentication; MAC-based authentication; DHCP snooping; DoS protection
-
SeriesProSAFE 10-Gigabit Smart Managed Switches
-
Spanning Tree ProtocolsIEEE 802.1D; IEEE 802.1w Rapid Spanning Tree; IEEE 802.1s Multiple Spanning Tree
-
Storm ControlBroadcast, multicast and unknown unicast storm control
-
Switching Technology10-Gigabit Ethernet
-
VLAN ID Range1 to 4093
Physical
-
Tvarový faktorRack-mountable
Paměť
-
Input Voltage Range100–240 V AC, 50–60 Hz
-
Jumbo Frame SupportUp to 9K bytes
-
Podpora multicastuIGMP snooping v1/v2/v3; MLD snooping v1/v2
Skladování
-
Management InterfacesWeb-based GUI; SNMP; RMON; CLI via console or telnet/SSH
-
Spínací kapacita560 Gbps
Moc
-
Power Consumption Maximum123 W
-
Power Consumption Typical84 W
-
Typ napájeníInternal power supply
Informace o prodejci
-
Záruka1
